Quick Links

• Page 2
  Preface We are very appreciated for you choosing and purchasing our car radio. To help you use this unit properly, we sincerely suggest you read the manual carefully. We will not inform you the specification or design update thanks to the technology improvement.

• Page 3: Table Of Contents

  Content Safety Precautions ………………….1 Main Menu ……………………3 Radio Operation ………………….6 DVD Player ……………………7 USB/SD Card Connection ………………..9 IPod ……………………..10 AUX Input ……………………11 Bluetooth Operation ………………..11 Bluetooth Music ………………….15 Navigation ……………………15 Screen Mirroring ………………….

• Page 4: Safety Precautions

  Safety Precautions Before installing this product 1. Use this unit with a 12-volt battery and negative grounding only.Failure to do so May result in a fire or malfunction. 2. To avoid shorts in the electrical system,be sure to disconnect the(-) battery cable Before installation.

• Page 5
  4. Keep this manual handy as a reference for operating procedures and safety information. 5. Do not install this unit where it may(i) obstruct the driver’s vision, (ii) impair the performance of any of the vehicle’s operating systems or safety features, including air bags or hazard lamp buttons or (iii) impair the driver’s ability to safely operate the vehicle.

• Page 6: Main Menu

  Main Menu ３…

• Page 7
  Return to the Home Screen Mute WiFi Connection Time Screenshot Recent Apps ４…
• Page 8
  Volume Brightness Return to the Previous Menu Apps Using: Tap an app to open it. Unit Customization Apps Arrangement Touch and hold any app on the Home screen, then drag the app around. Drag an app to the edge of the screen to move it to a different Home screen. Swipe left or right to see other screen.

• Page 9: Radio Operation

  Radio Operation AF: Alternative Frequencies TA: Traffic Announcement PTY: Program Type Broadcast frequency slider Perform manual tuning 6. P1/P2/P3/P4/P5/P6:Preset channel list (Select a frequency you like, then touch and hold any of preset frequency keys to store it. Up to 18 FM stations and 12 AM stations can be stored in memory.) Perform seek tuning or non-stop seeking tuning ST: mono/stereo switch…

• Page 10: Dvd Player

  DVD Player CAUTION 1. There are two screws on the top face of the unit to protect the disc drive in transit. These screws need to be removed first before installation. Otherwise it cannot accept or play discs. 2. For Safety reasons, video images cannot be view while your vehicle is in motion. To view video images, please stop in a safe place and apply the parking brake.

• Page 11: Dvd Player Interface

  DVD Player Interface 1. Repeat play: Choose to repeat the current file, repeat all files and repeat off. 2. Equalizer adjustment: Choose from Rock,Pop, Jazz, Classic, Flat, Voice and Custom. 3. Previous file 4. Pause/Play 5. Stop 6. Next file 7.

• Page 12: Usb/Sd Card Connection

  USB/SD Card Connection Please plug a USB storage device or insert an SD memory card to this unit, then tap Music on the Home screen to play music, tap Video on the Home screen to play video files or tap Photo or Gallery to view the images and photos. ９…

• Page 13: Ipod

  IPod Control your iPod/iPhone directly from your car dashboard and enjoy music playback on superior sound quality. 1. Repeat play: Choose to repeat the current file, repeat all files and repeat off. 2. Equalizer adjustment: Choose from Rock, Pop, Jazz, Classic, Flat, Voice and Custom.

• Page 14: Aux Input

  AUX Input You can display the video image output by making the device connected to this unit. CAUTION For Safety reasons, video images cannot be view while your vehicle is in motion. To view video images, please stop in a safe place and apply the parking brake. Bluetooth Operation Keypad Recent calls…

• Page 15
  CAUTION For your safety, please avoid talking on the phone as much as possible while driving. Bluetooth Connection (Bluetooth pairing) 1. The Bluetooth device must be within 1 meter from this unit. Turn on Bluetooth on the device. 2. You can find this unit in the devices list of your Bluetooth device. 3.

• Page 16: Phone Book

  Phone Book Please press to synchronize the contacts from your Bluetooth device. Recent Calls View recent outgoing phone calls, incoming calls or missed calls. １３…

• Page 17: Bluetooth Settings

  Devices List Tap a device of the paired devices or on the available devices list, then tap to pair the device. Tap to unpair the device. Bluetooth Settings 1. You can change the Device Name of this unit. Tap KSP to enter a different name. 2.

• Page 18: Bluetooth Music

  Bluetooth Music After the Bluetooth connection is established, tap A2DP on the Home screen, thenyou can play music stored in your Bluetooth device on this unit. ※ At first, you need to operate the music playback on your Bluetooth device, then you can operate the Bluetooth music on this unit.

• Page 19: Screen Mirroring

  Built-in navigation offers detailed, reliable route guidance information to help you get where you want to go. You can actually download a range of GPS Navigation apps via Google Play and run them on the unit. You can download Sat Nav apps like TomTom, Navigon, Route 66, Sygic, iGO, Google Maps and many more.

• Page 20: Connect Via Usb Cable

  For Android smart phone: 1. Connect via USB cable a. Go to Settings→About Device, then tap Build number 7 time to enable Developer options. Turn on USB debugging. A message “Allow USB debugging?” will pop up. Turn Always allow from this computer on, then tap OK. b.

• Page 21: Internet Connection

  Internet Connection You can connect this unit to the Internet whenever necessary, using a Wi-Fi connection (if available) or 3G/4G network (3G/4G dongle is sold separately). You can browse the web, download apps via Google Play, play online games, etc. The possibilities are endless with the Internet in your car.

• Page 22: Din Dvd(Optional)

  1 DIN DVD(Optional) This unit can support 1 Din DVD player. The 1 Din DVD player which can support all Android large screen navigation through the USB connection is placed in the storage box, and its installation is very easy. To add a 1 Din DVD player to this car radio, please Plug the USB cable to the USB port at the back of the radio.

• Page 23
  With a 1 Din DVD Player, you can play DVD and CD through this machine when you don’t have DVD player in the car. After USB connecting, you can play the DVD and CD in ２０…

• Page 24: Obd2(Optional)

  OBD2(Optional) This unit can support OBD2(On-Board Diagnostics) car diagnostics. With OBD2 function available on this unit, you can retrieve real-time data and trouble codes from your vehicle computer. All the data of your vehicle is displayed to you. (OBD2 Bluetooth car diagnostic scanner tool is sold separately.) The OBD II scanner tool should be correctly plugged into the OBD interface of the car.

• Page 25: Dvr(Optional)

  DVR(optional) You can control a car DVR camera (sold separately) on this unit and use it to record all the events of a journey. It is used for recording the whole process of traffic accidents, taking photos for front of vehicles and storing the video in real-time while driving.

• Page 26: Dab+(Optional)

  DAB+(Optional) With the use of a DAB dongle(sold separately), DAB+(Digital audio broadcasting) tuner lets you enjoy the convenience of digital radio, while Auto DAB+ Tuning makes sure there are less signal interruptions. DAB+ digital radio brings you high detail, digital-quality sound, lots of stations, program information and more. DAB antenna(sold separately) needs to be positioned on the windscreen of your vehicle.

• Page 27: Rearview Camera (Optional)

  Click into DAB+. Rearview Camera (Optional) With a rearview camera added this product, it can automatically switch to the parking image while reversing, which can effectively ensure your parking safety. (rear view camera is sold separately.) To add a rearview camera to your car, you should: a.

• Page 28
  h. Make the car rearview camera cable connects to the video extension cord. i. Hang up the reverse gear, you will see the signal automatically switches, and then the installation is completed. Here shows you the wiring of wireless rear view camera. ２５…

• Page 29: Carplay Usb Dongle (Optional)

  If you still can’t get reversing camera image at reverse gear after installing your wireless camera according to the above way, please find and connect the brown “CCD AV IN”cable (or REVERSE cable in the supplied power harness) to + positive of your reverse lamp.

• Page 30
  ２７…

• Page 31: Tpms (Optional)

  TPMS (Optional) This unit can support TPMS (Tire Pressure Monitoring System). An ideal tire pressure monitoring system (TPMS) can monitor tire gradual air leakage, quick air leakage, low or high tire temperature, low or high tire pressure, real-time alarm once the tire is abnormal.

• Page 32
  Click into TPMS interface. Click into more setting. ２９…

• Page 33: Digital Tv (Optional)

  Digital TV (Optional) This unit can support Digital TV receiver on three standards including ATSC, DVB-T and ISDB. With an amazing Digital TV signal receiver added to this product, you can have a wide range of choices for wonderful TV shows to enrich your driving experience.

• Page 34: External 3G Module (Optional)

  External 3G Module (Optional) With an external 3G module (which is sold separately), you can insert an SIM card to it, connect it to this product and then successfully connect to 3G Internet. About the installation, you should know: a. SIM card should be able to support WCDMA net. b.

• Page 35: External 4G Module (Optional)

  External 4G Module (Optional) With an external 4G module (which has USB dongle function as well), you can insert an SIM card to it, connect it to this product and then successfully connect to 4G Internet. (External 4G module is sold separately.) About the installation, you should know: a.

• Page 36: Google Play Store

  Google Play Store Google Play brings together all your favorite movies, TV programs, books, music, magazines, apps and more in one place. If you purchased content on Google Play in the past, you will automatically have access to this content on any Android device. Just make sure that you have signed in using the same account that you used to purchased it.

• Page 37: Device

  2. Device 2.1 Display 2.1.1 Brightness level Drag the slider to adjust the screen brightness. 2.1.2 Wallpaper Set an image or photo as wallpaper for the Home screen. 2.2 Sound 2.2.1 Key tone Turn Key tone on or off. 2.2.2 Volumes Drag the slider to adjust the volumes.

• Page 38
  2.5 Elements This enables you to change the illumination color of the buttons to your personal preference. You can choose from a wide variety of colors. Drag the color bars of red, green and blue to create a favorite color. ※…

• Page 39: Personal

  3. Personal 3.1 Security a. Device administrators b. Unknown sources c. Storage type d. Trusted credentials e. Install certificates from SD card f. Clear credentials g. Trust agents i. Apps with usage access 3.2 Accounts Add accounts: Add a Google account or other accounts. 3.3 Language &…

• Page 40
  3.4 Backup & reset a. Back up my data Back up app data, Wi-Fi passwords, and other settings to Google servers. b. Backup account c. Automatic restore d. Factory data rest Erase all data on the unit ３７…

• Page 41: System

  4. System 4.1 Date & time Date & time settings include: a. GPS automatic update b. Automatic date & time c. Automatic time zone d. Set date e. Set time f. Select time time g. Use 24-hour format 4.2 Accessibility a.

• Page 42: Car

  h. Touch & hold delay j. Color inversion k. Color correction 5. Car 5.1 GPS 5.1.1 GPS application options Choose which GPS application you want to use for the navigation. 5.1.2 GPS monitoring Turn GPS monitoring on or off. 5.1.3 GPS sound mode 5.1.4 GPS mixing ratio 5.1.5 GPS monitor 5.1.6 Location…

• Page 43
  5.3 Extra settings 5.3.1 Shutdown delay when ACC OFF Choose from 30 seconds, 5 minutes, 10 minutes, 30 minutes, 1 hour and 2hours. 5.3.2 Playing music Turn this on to allow the unit to play music automatically when you plug a USB storage device or insert an SD memory card.
• Page 44
  Choose from Driver, User, Front, Rear and All. 5.5 Steering wheel keys This allows you to use the steering wheel control of your vehicle to control the unit. Note: if your car has CAN BUS system, the SWC will be controlled by CAN BUS, and you don’t need to set in this way.
• Page 45
  After you enter the correct password, you can see more setting pages, as shown below. ４２…
• Page 46
  5.6.1 Application Change the options for Bluetooth, DVD,TV and iPod. 5.6.2 Car logo Select one of the preinstalled car manufacturer logos as your start up screen. You can also select images imported from an SD memory card. You need to insert the SD memory card into the GPS card slot.
• Page 47
  5.6.4 Voice Adjust the volumes of TV, DVD, iPod, System, AV Input, Radio and Bluetooth modes. 5.6.5 CanBus Change the options for Canbus 5.6.6 Key Study a. Panel key study b. Touch key study ４４…
• Page 48
  5.6.7 Other Change the options for RDS, Front Camera, Panel LED type and more. 5.7 About device See information about the unit. The items you can view mainly including: a. System updates b. MCU Update c. Model Number d. Android Version e.

• Page 49: Troubleshooting

  Troubleshooting If you meet problems when operating this product, please refer to this section. The most common problems are listed below, along with likely cause and solutions. Problems Cause Solutions 1. Car engine has not been Start the car engine. started.

• Page 50
  1. Video DVD settings do not Adjust video DVD Image flashes or match with the DVD. setting. distorted 2. Video connection is incorrect. Check the wiring. Select other stations 1. Signals are too weak. with stronger signal. 2. The vehicle antenna Check the connection Noise in broadcast connection is incorrect.
• Page 51
  ４８…
• Page 52
  ４９…
