psa235 COVER 1 17/6/05 10:14 Page 1

1

We hope you enjoy your product.

Please visit www.philips.com/support to view:

— FAQ, Frequently Asked Questions

— Latest user manuals

— Latest PC software downloads

— Firmware upgrade files and Device Manager

Since it is possible for you to upgrade your product,

we recommend that you register your product on

www.philips.com/register

so we can inform you as soon as new free upgrades become available.

The model and production numbers can be found inside the battery compartment.

About your new product

With your newly purchased product, you can enjoy the following:

— MP3 and WMA playback (see MUSIC MODE section)

— FM radio*** (see RADIO MODE section)

— Workout progress tracking

***FM radio is only available to some regional versions. FM radio is currenlty not available in Europe.

Included accessories

Headphones USB cable

1 x AAA Armband

CDROM with user manual, drivers, FAQ, music management softwares

PSA235_ENG.qxd 15/8/05 17:50 Page 1

2

About Batteries

You can use the following batteries with your device:

— normal batteries type LR03, UM4 or AAA (preferably Philips); or

— alkaline batteries type LR03, UM4 or AAA (preferably Philips); or

— rechargeable batteries type LR03, UM4 or AAA (preferably Philips)

Note: Remove batteries if they are empty or if the player is not going to be used for a long time.

Inserting batteries

Use an appropriately-sized coin to twist

anti-clockwise to unlock the back cover.

Insert a new battery with correct polarity.

(See printed label in battery compartment.)

Match the latches on the cover with the slots

on your device. Twist clockwise gently to

replace the back cover.

TIP

You can also twist open the cover without using a coin.

Grip on the rubber part of the back cover. Without moving your gripping

point, gently twist anti-clockwise to open.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 2

3

Powering on / off

Power on: Press and hold 2;.

➔PHILIPS splash screen appears briefly

Power off: Press and hold 2; again.

TIP

Your device automatically powers down if there is no operation and no

music played for 10 minutes. Last playback status / screen will be resumed

at next powering on.

✔

Indication of power level

You can see the approximate power level of your batteries on the display.

Battery full

Battery two-thirds full

Battery half full

Battery low

Battery empty

Note: Rechargeable batteries shows lower voltage levels when compared to alkaline ones.

Batteries contain chemical substances, so they should be disposed of properly.

TIP

When the batteries are nearly empty, the battery low screen blinks and

the beep tone sounds once.

When you hear a double beep, your device will power down.

Your device will save all settings and un-finished tracking before it powers down.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 3

4

Front of device

1Talking stopwatch Activates voice feedback telling you «elapsed time»

2Stopwatch Press to start, pause, or reset

3Previous Rewinds / Up 1 level / Skip to previous

4Display Dynamically displays menu, options and track information

5VOL — / Move down Navigate down / volume down in playscreeen

6VIEW To switch between root menu, library and now playing screens

7Next Fast forward / Down to 1 level / Skip to next

8Lock key Disables / enables key lock and ShockLock

92; Power on / off and Play / Pause

0VOL + / Move up Navigate up / volume up in playscreeen

PSA235_ENG.qxd 15/8/05 17:50 Page 4

5

Back of device

1Battery

2Card slot Mini SD Insert your mini SD* card here for memory expansion

3USB jack

4Back cover Insert a coin here to twist open / close back cover;

connects to arm band

5pAudio jack

*SD card is not by-packed.

PSA235_ENG.qxd 15/8/05 17:50 Page 5

6

Root menu

When your device powers up, you will see the ROOT MENU.

***FM radio is only available in some regional versions. FM radio is currenlty not available in Europe..

Navigation

Your device has an intuitive menu navigation system to guide you through various

settings and operations. Use 3,4,1,2to browse through menus. Press 2to

confirm your selection.

Music enter to play your digital music tracks

Radio*** enter to listen to your radio presets

Sport enter to view your workout summary

Settings enter to customize settings for your device

TIP

Select Shuffle All to play all your device music in a random way.

Smart Hide is a function to hide some library information. With Smart Hide, you can scroll

faster to the right content by hiding albums and artists which contain songs that are fewer

than a specified number.

Smart Hide 1 will hide all artists and albums that has only 1 track in the library.

Smart Hide 2 will hide all artists and albums that has only 2 or fewer tracks in the library.

Smart Hide 3 will hide all artists and albums that has only 3 or fewer tracks in the library.

Smart Hide 4 will hide all artists and albums that has only 4 or fewer tracks in the library.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 6

7

Music mode

We have put some music tracks on your device so that you can jump start your music experience.

You can also transfer your digital music collection from your computer to your device through the

included music management software.

(see GETTING DIGITAL MUSIC ON YOUR DEVICE for more information)

IMPORTANT!

We recommend that you the Sync function in Windows Media Player 10 to

transfer music to your player.

Searching for your desired music

1From the root menu, select MUSIC to enter the music mode. As you enter the music

mode, you can search from the following display options:

2Press 3to scroll up or 4to scroll down for your option.

Press 2for next or 1for previous levels.

3Press 2; to play your selection.

TIP

You can also press and hold 3or 4key to SuperScroll.

An enlarged head letter will show as the tracks scroll

quickly.

Stop pressing when you have arrived at your desired

head letter.

✔

Playlists Playlists

collections

Tracks listed in

play order

All songs Shuffle All

Alphabetically

listed tracks

Alphabetically

listed albums

Artists Alphabetically

listed artists

Alphabetically

listed artists

Genres Alphabetically

listed genres

Tracks listed in

album order

Albums Alphabetically

listed albums

Tracks listed in

album order

Alphabetically

listed albums

Tracks listed in

album order

Note: If your music is missing any ID3 tag information, then your may find empty fields or an indication

stating «No artist found» or «No album found» or «No genres found».

PSA235_ENG.qxd 15/8/05 17:50 Page 7

8

Playback

The keys: 2; ,0,5,3,7(see drawing on page 4) are multi-funtional. They work according to

how you press them: press or press and hold. During music playback, you can do the following:

Pause music Press 2; during playback

Go to next track Press 7

Go to previous track Press 3

Forward search Press and hold 7

Backward search Press and hold 3

Volume control 0/ 5

Basic Operation Controls to press

Customizing playback

Changing play modes

1From the root menu, select Settings.

2Use scroll controls to select the following options. Press 2; to confirm your selection.

Press 2; to deselect a checked option.

Changing Bass Enhancement

1From the root menu, select Settings > DBB.

2Use scroll controls to select On or Off.

Changing equalizers

1From the root menu, select Settings > EQ.

2Use scroll controls to select Rock,RnB,Electronica,Hip Hop,Classical,Jazz.

Shuffle On Off

Repeat Off On

Shuffle and repeat On On

Normal Off Off

Play mode Shuffle Repeat

PSA235_ENG.qxd 15/8/05 17:50 Page 8

9

Getting digital music onto your device

Before you can transfer your MP3 and/or WMA collection to your device using Windows Media

Playe, you need to have both Windows Media Player and Philips Device Manager installed on your PC

as follows:

Install Philips Device Manager and Windows Media Player

1Insert the supplied CD into your computer’s CD-ROM drive.

If the CD does not autorun, please click the .exe from the root directory of the CD.

2Select your language and follow screen instructions to complete installation of Philips

Philips Device Manager and Windows Media Player.

Connect your device to the computer

1Connect your device to your computer using the supplied USB

cable. A USB connection animation will be shown as soon as your

device is connected.

2You can organize files and transfer music to your device during

USB connection.

Organize and transfer your music using Windows Media Player 10

1Launch Windows Media Player from Windows desktop or Start menu.

2To transfer files from your computer to your device, click Copy to CD or Device / Sync tab.

3In the Items to Copy pane, in the drop-down list, click the playlist, category, or other item that

you want to copy.

4Clear the check boxes next to any files you do not want to copy.

5In the Items on Device pane, in the drop-down list, click the device that you want to copy files

to. i.e. PHILIPS GoGear / PHILIPS device.

6Click the Start Sync button.

Music files may be transferred using Windows Explorer (by drag and drop) to your

device only if they are saved in the following folder: «media»

If your Windows Media Player is open when you connect your device, your device

may not be recognized.

To transfer music files to the mini-SD card, you must format the mini-SD card the frist time

it is inserted to the device, and keep using it with the device. Otherwise, files transferred

cannot be recognized in Windows Media Player or Windows Explorer.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 9

10

Radio mode***

***FM radio is only available to some regional versions. FM radio is currenlty not available in Europe..

Select your FM region

1From the root menu, select Settings > Advanced > Radio settings.

2Select your region. Press 2to confirm your selection.

Auto tune

1From the root menu, select RADIO to enter the radio mode.

2Press 1from P1 or 2from P10 to select Autotune.

Press 2; to confirm.

➔Your device will automatically select the 10 strongest available

stations. Press any key to abort

Playing a radio station

1From the root menu, select RADIO to enter the radio mode.

2Press 1for the previous or 2for the next preset.

Manual tune

1From the radio play screen, press and hold 2to start manual tune.

2Press 1or 2to tune step by step.

➔The screen indicates the change in frequency. You will hear a

hissing sound / the tuned station as you manual tune.

3Press and hold 1to search for the last available station or press and hold 2to search for the

next available station.

4Press 2; to confirm and save your preset.

TIP

If you do not want to store a manual tuned preset, do not press any key.

The manual tuning screen will time out without saving.

The headphone wire is used as an FM antenna. If necessary, move it for

optimum reception.

✔

TIP

we recommend that you connect the bypacked headphones during auto tuning of your radio

presets since the headphone cable functions as an antenna.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 10

11

Tracking your workout progress

You can use your device as a stopwatch to track your workout progress.

All stopwatch activities will be recorded and stored on your device.

During use of stopwatch, you may press the talking stopwatch key to hear your elapsed time via the

headphones.

The screen shots below show what you see when you are using stopwatch.

The talking stopwatch voice feedback is available in: English, French, German and Spanish only. These

are linked to the language selection that you make in Settings. All other languages have English voice

feedback.

Go to stopwatch screen Press and hold 2(see «Front of device section» on p.4)

Start timing Press 2from stopwatch screen

Pause timing Press 2when stopwatch is active

Resume timing Press 2when stopwatch is paused

Reset stopwatch Press and hold 2

Stopwatch operation Controls to press

Using the stopwatch

You can use your device as a stopwatch to track your workout progress.

1From root menu, select Sport > History.

2You can view a list of recorded workout logs. Press 2to view details. You will see the date of

your workout and the elapsed time of your workout.

PSA235_ENG.qxd 15/8/05 17:50 Page 11

12

Using the talking stopwatch

1Press «clock» to start stopwatch.

2Press «talking stopwatch» for elapsed time.

3Press clock to stop stopwatch.

The talking stopwatch voice feedback is available in: English, French, German and Spanish only. These

are linked to the language selection that you make in Settings. All other languages have Engllish voice

feedback.

PSA235_ENG.qxd 15/8/05 17:50 Page 12

13

Customizing settings

1From the root menu, select Settings.

2Press 3to scroll up or 4to scroll down for your option. Press 2for next or 1for

previous levels.

3Press 2to confirm your selection.

4Press 1once or more to exit the menu display.

Shuffle Play tracks in random order

Repeat Play tracks repeatedly

PowerSave Battery power saving mode

DBB Base enhancement

Equalizer Rock / R&B / Electronica / Hip Hop / Classical / Jazz / Off

Backlight 5 seconds / 10 seconds / 30 seconds / Off

Contrast Levels 1 — 6

Language English, French, German, Spanish, Italian, Portuguese

(Brazilian), Dutch, Swedish, Polish, Chinese (Simplified),

Chinese (Traditional), Japanese, Korean

Factory settings Restore factory settings

Information Free space / About

Advanced

Radio Settings Europe / USA / Japan

Smart Hide Off / 1 / 2 / 3 / 4

Voice Feedback On demand / On time

Setting Function

TIP

Options for each setting are shown on the device display.

✔

TIP

— PowerSave is a battery power saving mode. During this mode, certain features that

consume high power, such as DBB and EQ are deactivated for opimal battery performance.

— Smart Hide is a function to hide some library information. With Smart Hide, you can scroll

faster to the right content by hiding albums and artists which contain songs that are fewer

than a specified number.

Smart Hide 1 will hide all artists and albums that has only 1 track in the library.

Smart Hide 2 will hide all artists and albums that has only 2 or fewer tracks in the library.

Smart Hide 3 will hide all artists and albums that has only 3 or fewer tracks in the library.

Smart Hide 4 will hide all artists and albums that has only 4 or fewer tracks in the library.

✔

PSA235_ENG.qxd 15/8/05 17:50 Page 13

14

Wearing player on your arm

1Attach device to armband, matching the

cover latch with the armband cup.

TIP

Ensure that the headphone socket is pointing upward.You will hear a click sound when you

have secured the player.

✔

2Connect headphones.

3Adjust fitting and wear on your arm.

PSA235_ENG.qxd 15/8/05 17:50 Page 14

15

Hang up Remove the battery. Re-insert the battery and power up

the device.

Cannot power up Insert new batteries. Press 2; and power up the device.

In case of device / card error, connect your device to the

computer. Use Device Manager to restore your device.

Device shows «Player problem» Device / memory card error. Connect your device to the

computer. Use Philips Device Manager to repair your device.

Device shows IIIIIIII You have transferred music tracks with Chinese, Japanese,

Korean or other languages to your device. Use Device

Manager to restore your device.

No sound when the 2; button is — You may have a weak battery, insert a fresh battery into your player.

pressed on my PSA player — Check if your headphone plug has been inserted into the head

phone jack of the unit completely

— When you press the 2; button, make sure that it is pressed

and held for long enough until the display light up.

— Check if the volume is at an audible level. Increase the volume

using the VOLUME + button.

— If psa is in pause mode, press the 2; button to resume playback.

— Do a soft reset by re-inserting the battery.

— If nothing works then try connecting your psa player to the

computer and then start Philips Device manager and select

«restore» to rebuild the database and firmware image of the

psa player

Cannot transfer from my PSA back This is not an error.Windows Media Player can only transfer tracks

to my computer from your computer back to your PSA but not the other way round,

subject to digital rights management.

Device shows » ! » / «Connect to PC» Connect your device to the computer. Use Philips Device Manager

to repair your device.

Symptom Solution

Troubleshooting

If a fault occurs, first check the points listed in the following pages. For further help and other

troubleshooting tips, please also check out FAQs at www.philips.com/support.

If you are unable to find a solution by following these hints, consult your dealer or service

center.

WARNING:

Under no circumstances should you try to repair the set yourself, as this will invalidate

the warranty.

PSA235_ENG.qxd 15/8/05 17:50 Page 15

16

Safety and Maintenance

General maintenance

To avoid damage or malfunction:

— Do not expose to excessive heat caused by heating equipment or direct sunlight.

— Do not drop your player or allow objects to fall on your player.

— Do not allow your player to be submersed in water. Do not expose earphone socket or

battery compartment to water as water entering the set may cause major damage.

— Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as

these may harm the set.

— Active mobile phones in the vicinity may cause interference.

— Backup your files. Please ensure that you retain the original files that you have downloaded

to your device. Philips is not responsible for any loss of content if the product becomes

damaged or not readable / legible.

— Manage (transfer, delete, etc.) your files only through included music software to avoid

problems!

About operating and storage temperatures

— Operate in a place where the temperature is always between 0 and 35ºC (32 to 95ºF).

— Store in a place where the temperature is always between -20 and 45ºC (-4 to 113ºF).

— Battery life may shorten in low temperature conditions.

Take care when using headphones

Hearing safety

Listen at a moderate volume. Using headphones at high volume can impair your hearing. We recommend

headphone no. SHJ025 for this product.

Important (for models with bypacked headphones):

Philips guarantees compliance with the maximum sound power of its audio players as determined by

relevant regulatory bodies only with the original model of provided headphones. In case this one

needs replacement, we recommend that you contact your retailer to order a model identical to that of

the original provided by Philips.

Traffic safety

Do not use headphones while driving or cycling as you may cause an accident.

PSA235_ENG.qxd 15/8/05 17:50 Page 16

17

Copyright information

— All other brand and product names are trademarks of their respective companies

or organizations.

— Unauthorized duplication of any recordings downloaded from the internet or made from

audio CDs is a violation of copyright laws and international treaties.

— The making of unauthorized copies of copy-protected material, including computer programmes, files,

broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal

offence.This equipment should not be used for such purposes.

Environmental information

We have reduced the packaging to its minimum and made it easy to separate into materials: cardboard,

PS, PE, PET.

Your set consists of material which can be recycled if disassembled by a specialized company

Please observe the local regulations to dispose of packaging, exhausted batteries and old

equipment.

Disposal of your old product

Your product is designed and manufactured with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means the

product is covered by the European Directive 2002/96/EC.

Please inform yourself about the local separate collection system for electrical and

electronic products.

Please act according to your local rules and do not dispose of your old products with your normal house-

hold waste. The correct disposal of your old product will help

prevent potential negative consequences for the environment and human health.

Modifications

Modifications not authorized by the manufacturer may void user authority to operate this device.

PSA235_ENG.qxd 15/8/05 17:50 Page 17

18

Notice for the USA

Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful

interference in a residential installation.This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

— Relocate the receiving antenna.

— Increase the separation between the equipment and receiver.

— Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

— Consult the dealer or an experienced radio/ TV technician for help.

Notice for Canada

This Class B digital apparaatus complies with Canadian ICES-003.

The set complies with the FCC-Rules, Part 15 and with 21 CFR 1040.10.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2.This device must accept any interference received, including interference that may cause

undesired operation.

Notice for the European Union

This product complies with the radio interference requirements of the European Union.

Philips

PSA232

PSA235

PSA242

PSA245

PSA235_ENG.qxd 15/8/05 17:50 Page 18

19

Technical Data

Power supply AAA Alkaline

Battery playtime 8 hours using 1 x AAA alkaline

Picture / Display Orange backlight LCD, 96 x 64 pixels

Sound Bass enhancement Digital Bass boost

Channel separation 50 dB

Equalizer customizable

Equalizer settings Rock / R&B / Electronica / Hip Hop / Classical / Jazz

Frequency response 30-18 000 Hz

Signal to noise ratio >80 dB

Output Power (RMS) 2 x 4 mW

Audio Playback

Compression format WMA (32-192 kbps and VBR )

WMA (5-192 kbps)

DRM WMDRM

ID3-tag support Album title and artist name

Storage Media

Built-in memory capacity PSA232 512 MB NAND Flash

PSA235 512 MB NAND Flash

PSA242 1GB NAND Flash

PSA245 1GB NAND Flash

Memory Card Types Mini SD card

Tuner / Reception / Transmission Auto store / Tuner band: FM***

***FM radio is only available to some regional versions. FM radio is

currenlty not available in Europe.

Connectivity Headphone 3.5 mm, USB

Music transfer via Windows Media Player 10

Data transfer via Windows Explorer

(note: Windows XP users only — music transferred via Windows Explorer to

“media” foldeer will playback)

System Requirements Windows XP(SP1 or above)

Internet connection

Microsoft Internet Explorer 6.0 or later

USB port

This product is protected by certain intellectual property rights of Microsoft Corporation. Use or distribution

of such technology outside this product is prohibited without a license from Microsoft or an authorized

Microsoft subsidiary.

Content providers are using the digital rights management technology for Windows Media contained in this

device («WM-DRM») to protect the integrity of their content («Secure Content») so that their intellectual

property, inlcuding copyright, in such content is not misappropriated.This device uses WM-DRM software to

playe Secure Content («WM-DRM Software»). If the security of the WM-DRM Software in this device has been

compromised, owners of Secure Content («Secure Content Owners») may request that Microsoft revoke the

WM-DRM Software’s right to acquire new licenses to copy, display and/or play Secure Content. Revocation

does not alter the WM-DRM Software’s ability to play unprotected content. A list of revoked WM-DRM

Software is sent to your device whenever you download a license for Secure Content from the Internet or

from a PC. Microsoft may, in conjunction with such licences, also download revocations lists onto your device

on behalf of Secure Content Owners.

Philips reserves the right to make design and specification changes for product improvement without prior notice.

*Note that some operating systems display capacity in units of “GB” where 1.0 GB = 230 = 1,073,741,834

bytes.The resulting “GB” capacity displayed by the OS will be smaller because of using this base-2 defiinition for

“Gigabyte”. 1 MB=1 million bytes. 1 GB=1 billion bytes; actual formatted capacity less.

PSA235_ENG.qxd 15/8/05 17:50 Page 19

1

About Windows Media Player

With Windows Media Player you can easily manage your digital music collection and transfer music to

your device. Music that has not been transferr to your device using Windows Media Player

can not be played on your device.

Install Windows Media Player and Device Manager

Insert the supplied CD into your computer’s’s CD-ROM drive.

1

Follow screen instructions to begin and complete installation.

2

Install Windows Media Player.

3

Fill in necessary information when prompted to do so.

4

About Philips Device Manager

With Philips Device Manager, you can update and restore/repair your

device with a few simple clicks.

wmp_ENG.qxd 15/8/05 11:00 Page 1

2

Launch Windows Media Player 10

Connect your device to your computer using the supplied USB cable.

The USB connection screen will automatically appear.

1

Launch Windows Media Player.

2

TIP

Please refer to your computer’s manual for the exact position of your USB port.

Look for the USB symbol on the processing unit of your computer.

✔

wmp_ENG.qxd 15/8/05 11:00 Page 2

3

Search and add tracks to the Library

Go to File menu. Click Add to Library > By Searching Computer.

1

Click Browse in the dialog box to point to the folder you want to add to.

2

Complete the information in the dialog box, and then click Search.

3

Files will be added to the Library.

4

*Actual display varies with use.

wmp_ENG.qxd 15/8/05 11:00 Page 3

4

Transfer tracks to your device

Click on Sync.

1

In the Items to Copy pane, show the playlist, category, or other items that you want to copy

that you want to copy. Clear the check boxes next to any files you do not want to copy..

2

TIP

Simply connect your device to your computer, choose the synchronization

method you want, and you’re ready to synchronize your library to your device.

Choose a synchronization method:

Automatic. With this option, the Player synchronizes content to the device when you connect

it to your computer or when you change synchronization settings.The Player synchronizes your

entire library if it can fit, or the Player synchronizes your favorite content first.

Manual. With this option, you pick specific files or playlists you want to synchronize each time

you want to make changes to the content on your device.

✔

wmp_ENG.qxd 15/8/05 11:00 Page 4

5

In the Items on Device pane, show the device that you want to copy files to, i.e. Philips GoGear

/Philips. Clear the check boxes next to any files you do not want to copy..

3

Click the Start Sync button

4

TIP

For further details of music transfer on WMP 10, go to the help section of Windows Media

Player and click Help > Synchronizing content to devices.

✔

wmp_ENG.qxd 15/8/05 11:00 Page 5

6

Add Tracks to a Playlist on your PC using WMP

Click to highlight an item.

1

Right click on the item and select Add to > Additional Playlist…

2

From the Add to Playlist pop-up window, select an existing playlist or add new one.

3

TIP

Press and hold <Ctrl> on your keyboard and click to select more than one item.

To select consecutive items, click the first item, press and hold <Shift> on your

keyboard, and then click the last item.

✔

The selection is added to playlist.

4

* Actual display varies with use.

wmp_ENG.qxd 15/8/05 11:00 Page 6

7

Click to highlight an item.

1

Right click and select Delete to delete.

2

TIP

Press and hold <Ctrl> on your keyboard and click to select more than one item.

To select consecutive items, click the first item, press and hold <Shift> on your

keyboard, and then click the last item.

✔

Delete Tracks and Playlists

* Actual display varies with use.

wmp_ENG.qxd 15/8/05 11:00 Page 7

8

Edit Track Information

Click on a track.

1

Right click and select Edit.

2

Click on the text boxes to edit relevant information.

3

*Actual display varies with use.

wmp_ENG.qxd 15/8/05 11:00 Page 8

9

Search for Tracks

Type a search string in the Search field.

1

Click on Search to start searching.

2

You will see tracks that contain the search string.

3

You can play, transfer, delete or add these tracks.

4

* Actual display varies with use.

wmp_ENG.qxd 15/8/05 11:00 Page 9

10

Upgrades

We know you will enjoy your product for a long time. For best performance, we recommend that

you regularly check in to www.philips.com for free upgrades of the latest software and firmware for

your product.

Firmware Upgrade

Your device is controlled by an internal program called firmware. You can install the latest firmware from

the bypacked CD and download it from www.philips.com/support to keep your device updated.

Connect your device to your computer (powered by the supplied AC/DC adapter if

applicable).

2

Select your device and click Upgrade, Device Manager will check whether a new firmware is

available and install it on your device.

4

TIP

Please insert a new battery before firmware upgrade. This will ensure steady power

supply for completing the whole process.

✔

In case you have chosen “Cancel”, the firmware present on the PC will be loaded onto the device.

7

Install the latest Philips Device Manager from the bypacked CD. Philips Device Manager will

automatically notify you if any new updates are available.

1

If your:

— internet connection is activated

— your Device Manager has been installed on your PC

— your device is connected and powered on

then your Device manager will pop-up a message if new firmware is available for your device

Launch Device Manager User Interface by right-clicking on this icon in the taskbar

and selecting “Launch Device Manager” or from the Desktop icons or by going to

Start ➔Programs ➔Philips Device Manager ➔ or from the desktop.

3

If a new firmware file is available for your device, you will be prompted to download the same.

You can choose “Ye s ” to download the latest firmware or choose “Cancel” to use the existing

firmware file on your PC.

5

The process is complete when the device restarts and displays the power up splash screen.

A success message will be displayed to you.

8

If you have chosen to download the latest firmware, after the download, the Device Manager will

prompt you for permission to load the firmware onto the device. On selecting “Ye s ” the latest

firmware will be loaded into the device.

6

WMP_ENG_battery_P17_P18_B 7/29/05 2:55 PM Page 17

11

Device Restore / Repair

Your device is controlled by an internal program called firmware. In case your device has

a problem, or you wish to format the device, you may need to restore / repair it.

1Connect your device to your computer. Launch Device Manager from Start ➔Program ➔

Philips Device Manager.

2Launch Device Manager User Interface by right-clicking on this icon in the

taskbar and selecting «Launch Device Manager» or by going to

Start ➔Programs ➔Philips Device Manager

3In the main window, go to the repair tab and click Repair.

4You will be prompted before repair begins.

5Click OK to continue. Click Cancel to stop.

6The Device Manager will repair your device. Once the repair is complete,

the device can be used again.

Your device will be automatically disconnected as soon as Device Manager finishes interacting

with your device and will get connected back to the PC after the repair is complete.

TIP

Please insert a new battery before device restore/repair. This will ensure steady power

supply for completing the whole process.

✔

ATTENTION!

All media contents will be erased!

WMP_ENG_battery_P17_P18_B 7/29/05 2:55 PM Page 18

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips Electronics N.V.

or their respective owners

2005 © Koninklijke Philips Electronics N.V. All rights reserved.

www.philips.com Printed in China

hdd1420 COVER 1 29/7/05 16:05 Page 2
