[. . . ] DIGITAL RECORDER
INSTALLATION MANUAL
OTHERS
MODEL
DX-TL308E DX-TL304E
THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER.
1
ENGLISH
Before use
How to use this manual
About this manual
The manual of this recorder consists of the following two manuals. Installation Manual (this manual) This manual describes connections of devices as well as functional settings and operations to use this recorder. This manual mainly describes operating procedures carried out by the mouse. [. . . ] Changing user settings
Step
4 Select [User Registration] on the [Completed] screen.
The [User Registration] screen is displayed.
Removing registered users
Step
You can change the settings related to the authorization of the registered users and remove registered users. You can also register new users.
Step
1 Select [remove] of the user ID that you want to remove using [Change authorities of users] on the [User Registration] screen.
1 Display the [Main Menu] screen according to page 81. steps 1 to 3 of «Login» on 2 Select [Configuration Menu].
The [Remove Confirmation] screen appears.
Step
2 To remove the user, select [remove].
Step
The [Configuration Menu] screen appears.
Step
To cancel, select [cancel]. The [User Registration] screen is displayed.
3 Select [User Registration] on the [Completed] screen.
The [User Registration] screen is displayed.
Registering new users
Step Step
3 Select [User Registration].
1 Enter a new user ID and password in [Add New User] on the [User Registration] screen. 3 To register the user, select [register].
The [User Registration] screen appears.
Step Step
The user is added to [Change authorities of users]. The settings you made are cleared.
Changing the settings of the registered users
Step
1 Change the settings using [Change authorities of users] on the [User Registration] screen.
[Authority] Live Monitoring . (This authority allows the user to load images from the cameras that are disabled by the covert camera setting ( page 105)). The user is allowed to view or change user registration information and configure certain settings of the recorder.
Step
2 Select [change].
The [Change Confirmation] screen appears.
84
You can set or change the titles of the recorder and cameras.
Step
1 Display the [Main Menu] screen according to page 81. steps 1 to 3 of «Login» on 2 Select [Configuration Menu].
Step
The [Configuration Menu] screen appears.
Step
3 Select [Recorder Title & Camera Titles].
The [Recorder Title & Camera Titles] screen appears.
Step
4 Enter a new title.
The current recorder title and camera titles are shown in the [Current text] boxes.
Step
5 Select [change].
When you select [Batch Registration], all the settings shown on the screen are determined.
Communication
85
ENGLISH
Setting the titles of the recorder and cameras
Using the communication functions (continued)
E-mail setup
DNS Settings To determine the settings shown in a row, select [set] of that row. When you select [Batch Registration], all the settings shown under [DNS Settings] are determined. OPTION Settings
For e-mail transmission, you can make settings related to the mail server, sender, and e-mail addresses of recipients.
Step
1 Display the [Main Menu] screen according to page 81. steps 1 to 3 of «Login» on 2 Select [Configuration Menu].
Step
The [Configuration Menu] screen appears.
Step
3 Select [E-mail Settings].
The [E-mail Settings] screen appears.
To determine the settings shown in a row, select [set] of that row. When you select [Batch Registration], all the settings shown under [OPTION Settings] are determined. [Image Attachment Delay] (DX-TL308E only): You can set the timing to capture an image to be attached by the image attachment function. You can set the interval between the occurrence of an alarm event and the image capturing to up to 10 seconds. [Retry Interval]: You can set the interval of retries performed when transmission is failed.
Step
5 Set the recipients’ addresses and e-mail contents in [Receiver’s Addresses].
Step
4 Make settings for the server to send e-mail using [E-mail Sender Setup].
You can set up to 3 addresses. When you select [Batch Registration], all the settings shown under [Receiver’s Addresses] are determined. [Remain]: With this option selected, notification is issued when the remaining capacity decreases to the preset value (by call-out setting). [Temp/Fan]: With this option selected, notification is issued when a high temperature is detected or the fan is stopped. [Reboot]: With this option selected, notification is issued when a failure occurs in the recorder. [Record]: With this option selected, notification is issued at the start of recording. [Alarm]: With this option selected, notification is issued at the start of alarm recording. [. . . ] (3) Zaklcenia pracy lub dezaktywacja urzdzenia wskutek szkodliwego dzialania osb trzecich. Aby zapobiec powyszym sytuacjom, naley na wlasn odpowiedzialno podj odpowiednie kroki w celu zabezpieczenia sieci. Naley ustali haslo sieciowe trudne do odgadnicia przez osoby trzecie. Ponadto haslo naley regularnie zmienia.
Others
27
OTHERS
Others (continued)
Zrzeczenie si odpowiedzialnoci
Firma Mitsubishi nie ponosi odpowiedzialnoci ani nie gwarantuje adnych odszkodowa za bldy w dzialaniu systemu nadzoru, utrat nagranych danych lub inne szkody lub straty powstale w wyniku bldnego dzialania urzdzenia. [. . . ]
