Package Contents

1. Ultra-slim Bluetooth keyboard with backlit
2. Micro-USB charging cable
3. User manual

Specifications

Getting Started Guide

Backlit of keyboard guide

1. Press the lighting key first time is turning on the light.
   Press second time is increasing brightness.
   Press third time is lighting off. (single color backlight)
2. to change the backlight colors.(7-color backlit) 3) When the battery is less than 20%,the backlights will turn off.

Led Display

CAPS	Lights blue when CAPS-lock is active
	Will flash blue (3min. long) after pressing the «Connect» button until a BT connection is established. It disappears when connected.
Charge	Lights red when the keyboard is charging. Turns off when the battery is fully charged. Flashes red, when the battery is weak and should be charged.
Power	Lights up blue for about 4 sec when being turned on.

Keys and Function

	iOS	Android	Windows	Fn on Windows
	Home	Home	ESC	Web browser
	Keyboard Display	N/A	F1	N/A
	Select all	Select all	F2	Select all
	Copy	Copy	F3	Copy
	Paste	Paste	F4	Paste
	N/A	Email	F5	Email
	Search	Search	F6	Search
	Select Language	N/A	F7	N/A
	Previous track	Previous track	F8	Previous track
	Play/pause	Play/pause	F9	Play/pause
	Next track	Next track	F10	Next track
	Volume —	Volume —	F11	Volume —
	Volume +	Volume +	F12	Volume +
	Lock screen	Lock screen	N/A	N/A

Note:
Press Fn and Q,W or E keys together to shift between iOS, Android or Windows systems after connected successfully. Otherwise the keyboard’s function key will be invalid. Q- iOS W- Android E- Windows

System requirements

iPad — All versions iPhones — All versions
Bluetooth-enabled PCs or Laptops with Windows XP / Vista / 7 / 8
Bluetooth-enabled iMac / Macbooks with Mac OS X 10.2.8 or above (note that some exceptions may apply. we guarantee hassle-free support and easy returns/exchanges)
Smartphones or tablets (not including Dell tablets) with Android 3.0 and above(with Bluetooth HID profile)
Windows Mobile 5.0 and above
This keyboard may not be compatible with the Mac mini.

SPECIAL NOTE:

1. This keyboard doesn’t support the Windows Mobile.
2. For Android users. The Caps Lock indicator may not light, but will still function normally.

Pairing keyboard method

• Step 1. On the keyboard, slide the power button on.
• Step 2. Press the connect button, the Bluetooth indicator light will be blinking blue.
• Step 3. On the iPad, select: Settings- General- Bluetooth-On.
• Step 4. The iPad will display «Bluetooth 3.0 keyboard» as an available device.
• Step 5. Select «Bluetooth 3.0 Keyboard» on the iPad, click on it, the keyboard will now be paired to iPad and the Bluetooth indicator will turn off.

SPECIAL NOTE

1. Only one device can be actively paired at one time.
2. After pairing for the first time, your device will connect to the keyboard automatically when opening the keyboard.
3. In case of connection failure, delete the pairing record from your device, and try the above procedures again.

Power Saving Mode

The keyboard will enter sleep mode when idle for 30 minutes. To re-activate it, press any key and wait for 3 seconds.

Charge it

1. Plug the micro end of the USB charging cable into the keyboard.
2. Plug the USB end of the cable into a computer or charging adapter (not included).If the red charge indicator light begins flashing during use, 4-hour recharge is recommended.

Warning

FCC Regulatory Compliance

changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired operation.

ISED Regulatory Compliance

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.

Bluetooth Keyboard

Model Name: HB030B

FCC ID: 2AAKTHB030B

HB030B Ultra-thin Bluetooth Keyboard

Packing Contents:

1. Keyboard

2. User manual

3. Micro-USB charging cable

*Bluetooth Keyboard Features:

1. Built-in Broadcom Bluetooth 3.0 module keyboard

2. For IPAD, Samsung, and other tablets which supports HID

3. MICRO interface, easy to charge

4. Built-in rechargeable lithium battery

5. Light weight, quiet keystrokes, dust-proof

7. Energy saving keyboard sleep mode

*Bluetooth Keyboard Specification:

1.Bluetooth 3.0 interface standard

2.Operating Distance to 10 meters

3.Modulating System: GFSK

4.Operation Voltage: 1.8-3.6V

5.Working Current: <2.0mA

6.Standby Current:：<0.3mA

7.Sleeping Current: <40uA

8.Charging Current:≥ 200mA

9.Standby Time: >30 days

10.Charging Time: <2 hours

11.Lithium Battery Capacity:160mA

12.Uninterrupted Working Time: 64 hours

13.Lithium Battery Life: 3 years

14.Lithium Battery Specification: 2.5*20*40mm

15.Key Strength: 80±10g

16.Key life: 5 million strokes

17.Operating Temperature: —10-+55 C

*Bluetooth Keyboard Pairing method

Step1: Press the button about 3 seconds. The blue status light will be on for 2 seconds and then

off .

Step2: Press the button again, the indicator light will be blinking,now the keyboard is

ready to connect to your device.

Step3: Turn your device bluetooth on and search our keyboard bluetooth signal,find”bluetooth 3.0

keyboard”

Step4: Input the code on the keyboard and press enter; when connected the indicator light will

be turn off automatically.

*Keyboard status light

1． ：Caps lock light: When press the status light will be on in blue,input words are

upper-ase status ,press the blue light will be off,the input words are lower-case status.

2. : Bluetooth status light: Press on the button, the status light will be blinking in

blue,status light will stay on until the keyboard connect with your device.

3. “ ”: Charging light（Red）: it will be red when charing and turn off when fully charged.

“ ”: Battery status light in Blue: when switch the keyboard bluetooth on,it is in blue

blinking and will be off in 3 seconds,When the power voltage under 3.2V, it is blue blinking

will blinking blue untill keyboard is out of power, light will be turn off automatically.

*Battery

The long-lasting rechargeable battery can service you for several weeks

With no memory effect, the lithium battery can be charged at any time.

In order to extend service life,we recommend you turn the keyboard off when there is long time

with no interactive.

*Charging

When the battery power is low, the[power] indicator light will start blinking,it is time to recharge

the keyboard.

Step1: Connect Mirco-USB of the native USB power cable to the keyboard charging interface.

Step2: Connect USB-A to the power adapter or computer’s USB interface.

Step3:the red indicator light will stay on when the keyboard is charging. Once it finished

charging the indicator light will turn off.

*Energy Saving Sleep Mode

The keyboard will kick into sleep mode when it is inactive for 15 minutes. To activate from sleep

mode, just press any key and wait 3 seconds ,the keyboard will come back on.

*Safety Caution

1. Keep the item away from sharp objects.

2. Do not place heavy object on top of the keyboard.

3. Do not Microwave the item.

4. Do not force or distorted the keyboard

5. Keep away from oil.chemical or any other organic liquid

*Cleaning

Clean the silicone keyboard with water, alcohol or alcohol based disinfectant

*Troubleshooting

A. Unable to connect

1.Make sure the power switch is on. (the power indicator is shine)

2.Make sure the keyboard is within the operating distance.(within 10 meters)

3.Make sure the battery storage have power.

4.Make sure the Bluetooth in tablet pc is on .

5.Press the key””, check the Bluetooth status.

6.The solution of above 1-5 questions:

The keyboard may long use has out of power, in such case charge battery can solve.

B.Unable to Charge Keyboard

1.Make sure the USB power cable is connected properly to the keyboard and the power source.

2.Make sure the wall charger is plug into the power outlet.

*Special Keys Description

Long press Fn and combination with F1-F12 and insert keys to the shift multimedia keys, and

mainly be used in the operation of tablets multimedia.

*Storing the Ipad for Travel

To store the Ipad

1.Line up the 30-pin port connector on the Ipad with the slot on the short end of the keyboard

case.

2.Place the Ipad screen down,into the keyboard case.

*Disposal of Waste batteries

Insert screwdriver between plastic top and metal case at keyboard top or bottom and Pry up

plastic top and remove it completely. This action destroys keyboard separate battery from

circuit board,it is your responsible to hand this over to an applicable collection and recycling will

help to conserve natural resources and prevent potential negative consequences for human health

and the environment due to the possible presence of hazardous in batteries and electrical and

electronic equipment.

According to China << Electronic information products pollution control measures>>

Important Regulatory Information

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

Changes or modifications to this unit not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.
